Vertical sand blasting machine
3
1.Molding speed up to 400~450 models/hour
2.The error rate is very small,only a small amount of casting machining allowance
3.Automatic template replacement device for quick template replacement
4.Synchronous clamping/holding conveyor issynchronized with the main engine ,Complete the mold transfer during the casting cooling process
5.Remote diagnosis ensures high efficiency
6.The molding room is sprayed with release agent,
7.Synchronous belt cooler :Depending on the cool- ing time of the casting ,Synchronization with gripper/support conveyor ,Extend the conveying time of sand mold
8.adjustable mold thickness and mold purge deviceAutomatic core removal device,Achieve fast and accurate on-line synchronous core unloading
- Products Details
- Products Video
- Related Products
|
The machine mode |
ZJ418YF |
ZJ418AF |
ZJ418DF/BD |
ZJ419AF |
ZJ419BF |
ZJ419XF |
ZJ419YF |
ZJ4110AF |
ZJ4110BF |
ZJ4111AF |
ZJ4112AF |
ZJ4113AF |
|
|
Sand mold size |
Width (mm) |
800 |
800 |
850 |
900 |
900 |
950 |
950 |
1000 |
1000 |
1100 |
1200 |
1300 |
|
|
Height (mm) |
600 |
600 |
650 |
650 |
700 |
700 |
800 |
800 |
900 |
1050 |
1100 |
1100 |
|
|
Thickness(mm) |
130～380 |
150～500 |
150～500 |
150～500 |
150～500 |
200～650 |
200～650 |
200～650 |
200～400 |
200～350 |
250～350 |
250～350 |
|
Molding speed (mold/H) |
450 |
350 |
350 |
330 |
330 |
280 |
280 |
280 |
200 |
200 |
200 |
200 |
|
